grandMA full-size

MA Lighting

Art.No.: 120301


The grandMA consoles are the core of the fully integrated MA system. This product family offers six different hardware platforms and provides immediate solutions ready for all kinds of applications – including theatres, musical events, concert touring, television, clubs, amusement parks or cruise ships. The grandMA consoles are able to control – in the most elegant manner – moving lights, conventional lights, and effects, as well as LEDs and video – even when working in real time with maximum channel count. Additionally MA offers powerful tools like the media server grandMA video which bridge the lighting and video worlds. Direct access to media servers from the grandMA console is now as simple as accessing a fixture. The grandMA 3D software is capable of real-time rendering visualization. The reliable and proven operational philosophy allows a direct, flexible and intuitive way of working.

The grandMA full-size is the extensive integration of conventional lighting control technology and moving light control in one console – the reliable operating philosophy has now been further developed and transferred to the fields of LED, visualisation and video.

The grandMA full-size is the original console in the range providing a truly flexible and comfortable programming and operating environment. It is also the largest console, capable of controlling huge numbers of devices in an elegant manner. Three color touch screen displays, two external displays, twenty motorized faders, 60+40 physical playback buttons (on 128 pages), an internal uninterruptible power supply and 2,048 DMX channels on-board, expandable to 4,096 DMX channels using an upgrade chip, makes this a luxurious environment for any console programmer. Combined with free visualization software, support for up to six remotes and 16,384 parameters (32,768 channels) with additional hardware for DMX universe expansion – the MA Network Signal Processor, the grandMA is not just the largest console of the range, but a large console in stature and features.


  • Real-time control for up to 64 DMX universes (Expansion Mode)
  • Extensive networking functionality incl. Multi-User, Backup, Parameter Expansion, etc.
  • 2,048 HTP- or LTP-parameters built-in (4,096 with expansion chip) in stand-alone mode
  • 3 internal, high-resolution TFT color touch screens
  • 2 external SVGA connectors
  • 20 motorized faders, 60+40 executor buttons (on 128 pages)
  • Keyboard and mouse included
  • Uninterruptable Power Supply (UPS) built-in
  • Same software for console compatibility: one system – one operating philosophy
  • Completely configurable for every application: Theatre, TV, Concert Touring, Entertainment, etc.
  • Elegant programming and control of moving lights, dimmers, LEDs, effects and media servers
  • Mature software and hardware – extensively field tested – provide unmatched stability and reliability

Supplied with

built-in keyboard
2x LED desk lamp
dust cover
power cable
English manual and grandMA – the DVD

Technical Specifications

Dimensions1200 x 670 x 150mm / 47.3 x 5.9 x 26.4inch
Net weight47kg / 90lbs
Number of channels2048/4096
Output connectorsXLR 5-polig (DMX)
Input connectorsCEE 22
Number of memoriesbeliebig

Product PDF




Teatro Nacional Cervantes – Buenos Aires - Argentina

Teatro Nacional Cervantes – Buenos Aires

Theatre 2018

  • 1 x grandMA2 full-size
  • 1 x grandMA2 ultra-light
  • 1 x grandMA full-size
  • 1 x grandMA micro
  • 1 x MA NPU (Network Processing Unit)
  • 1 x MA NSP (Network Signal Processor)
  • 1 x 2Port Node onPC Pro

AT&T Dolphin Tales

Concert Touring/Live Event 2011

  • 1 x grandMA full-size
  • 1 x grandMA light

Dragonflies & Astronauts - Johannesburg

Concert Touring/Live Event 2011
South Africa

  • 1 x grandMA full-size

RAIN - A tribute to the Beatles

Concert Touring/Live Event 2011

  • 2 x grandMA full-size
  • 2 x MA NSP (Network Signal Processor)

X-Factor 2010 - Cologne

TV/Film 2010

  • 21 x Clay Paky Alpha Beam 700
  • 36 x Clay Paky Alpha Spot 1200
  • 8 x Clay Paky Alpha Spot HPE 1500
  • 8 x Vari*Lite VL1000 TS
  • 6 x Vari*Lite VL3500 Spot
  • Rainbow Colour Changer 15" PRO2
  • 2 x Robert Juliat Topaze
  • 4 x grandMA full-size
  • 1 x grandMA light
  • 3 x MA NSP (Network Signal Processor)

Prince "Welcome 2 America" - World Tour 2011

Concert Touring/Live Event 2010

  • 2 x grandMA full-size
